PR-3 5-Axis Machining on SW Machines

SHORT DESCRIPTION

The objective of this training is to deepen the handling of the SW machine control regarding the 5-axis simultaneous machining. After expanding the knowledge of the control of the machine, special attention will be given to program functions and measurements which are necessary if 5-axis machining is to be carried out on a SW machine. The acquired knowledge will be deepened by practical exercises on a training machine.

LEARNING OBJECTIVES

After the successful completion of this course, the participant will be able to reduce the machining time of the SW machine for workpieces with complex surface geometry and further to improve the precision of 5-axis machining by

| Modifying or recreating an appropriate CNC program and installing it on the SW machine,
| Ensuring the faultless functioning of the program through tests and initiating the modified production sequence.

Target group

Prerequisites

| Successful participation in the course “PR-2 Advanced CNC-Programming of SW Machines” or
| Successful participation in the course “PR-1 Basic CNC Programming of SW Machines” with additional programming experience

Content overview

| Safety regulations and accident prevention instructions
| Programming 5-axis machining on SW machines
| Simultaneous machining

Course duration

3 days

Max. Number of participants

4
